PAINTED PLANETARY MIXER INVERTOR

PAINTED DOUGH SHEETER ON BASE
600 x 1400 mm
‐ It is compact and with a design that allows the operator to work comfortably.
‐ The dough sheeter is perfect for multiple applications: from pastry shops to hotels, catering, etc.
‐ Existing options have been made even more advanced.
‐ Optional: collecting dough tray, the display allows you to
precisely check the decrease of calibrator cylinders.
‐ Cylinders opening (mm): 40
‐ Cylinders diameter (mm): 80
‐ Conveyor belts width (mm): 600
‐ Power (kw): 0,75
‐ Power (hp): 1
• Weight: 190 kg • Voltage: 400V / 50 Hz / 3 ph
• Dim [mm]: 3215 x 1080 x 1375
Model No. SHB60B140B / Z.MATIK / ITALY

500 x 1200 mm
‐ It is compact and with a design that allows the operator to work
comfortably.
‐ The dough sheeter is perfect for multiple applications: from pastry shops to hotels, catering, etc.
‐ Existing options have been made even more advanced.
‐ Optional: collecting dough tray, the display allows you to precisely check the decrease of calibrator cylinders.
‐ Cylinders opening (mm): 40
‐ Cylinders diameter (mm): 80
‐ Conveyor belts width (mm): 500
‐ Power (kw): 0,55
‐ Power (hp): 0,75 • Weight: 180 kg • Voltage: 400V / 50 Hz/ 3 ph
• Dim [mm]: 2790 x 980 x 1375
Model No. SHB 50B120B / ZMATIK / ITALY
